مقياس الضغط من -100 إلى 2000 مليبار من النوع GMH 3161-13 - 9040007 | Self Endüstriyel

مقياس الضغط من -100 إلى 2000 مليبار من النوع GMH 3161-13

852.40 €
بدون الضريبة
آخر عناصر في المخزون
مشاركة

المواصفات الفنية
الوزن 0.260 kg
hose connector 4 mm
connections 2
measurement range -100 up to 2000 mbar
resolution 1mbar
accuracy (temperature dependency) ±0.4%FS
الأبعاد 142x71x26 mm
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
interface serial (adapter not included)
sensor piezoresistant gauge pressure sensor, int.
function vacuum/over-/differential-pressure
operating positions min/max value, tare, hold
measurement unit bar,kPa,MPa,mmHg,PSI,mH2O
النوع GMH 3161-13
scope of delivery incl. battery
probe type relative pressure sensor
switching capacity vacuum/over-/differential-pressure
mounting distance incl. battery
probe type relative pressure sensor
scope of delivery incl. battery
thread size 4 mm
operating positions min/max value
connections 2
display 1mbar
display serial (adapter not included)
measurement range -100 up to 2000 mbar
measurement unit bar
accuracy (temperature dependency) ±0.4%FS
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
sensor piezoresistant gauge pressure sensor

رقم المرجع: 800.000

switching capacity vacuum/over-/differential-pressure
mounting distance incl. battery
probe type relative pressure sensor
scope of delivery incl. battery
thread size 4 mm
operating positions min/max value
connections 2
display 1mbar
display serial (adapter not included)
measurement range -100 up to 2000 mbar
measurement unit bar
accuracy (temperature dependency) ±0.4%FS
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
sensor piezoresistant gauge pressure sensor
switching capacity vacuum/over-/differential-pressure
mounting distance incl. battery
probe type relative pressure sensor
scope of delivery incl. battery
thread size 4 mm
operating positions min/max value
connections 2
display 1mbar
display serial (adapter not included)
measurement range -100 up to 2000 mbar
measurement unit bar
accuracy (temperature dependency) ±0.4%FS
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
sensor piezoresistant gauge pressure sensor
switching capacity vacuum/over-/differential-pressure
mounting distance incl. battery
probe type relative pressure sensor
scope of delivery incl. battery
thread size 4 mm
operating positions min/max value
connections 2
display 1mbar
display serial (adapter not included)
measurement range -100 up to 2000 mbar
measurement unit bar
accuracy (temperature dependency) ±0.4%FS
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
sensor piezoresistant gauge pressure sensor
switching capacity vacuum/over-/differential-pressure
mounting distance incl. battery
probe type relative pressure sensor
scope of delivery incl. battery
thread size 4 mm
operating positions min/max value
connections 2
display 1mbar
display serial (adapter not included)
measurement range -100 up to 2000 mbar
measurement unit bar
accuracy (temperature dependency) ±0.4%FS
accuracy (hysteresis and linearity) ±0.2%FS
overload max. 4 bar
sensor piezoresistant gauge pressure sensor
OEM Üretici Markaları (1)
GEV
800000
Eski Kod: 800.000

  • المرجع
    9040007
  • السلع الموجودة بالمخزن أولا
    2 عناصر
  • measurement range
    -100 up to 2000 mbar
  • display
    1mbar
    serial (adapter not included)
  • connections
    2
  • thread size
    4 mm
  • accuracy (hysteresis and linearity)
    ±0.2%FS
  • accuracy (temperature dependency)
    ±0.4%FS
  • measurement unit
    bar
  • mounting distance
    incl. battery
  • scope of delivery
    incl. battery
  • overload
    max. 4 bar
  • operating positions
    min/max value
  • sensor
    piezoresistant gauge pressure sensor
  • probe type
    relative pressure sensor
  • switching capacity
    vacuum/over-/differential-pressure
